VRV Outdoor Air Processing Unit
VRV Outdoor Air Processing Unit is designed with the latest technology to cater to your air side needs.
Features
VRV Ducted Unit with EC Fan
Biggest cooling capacity of 56.0kW
Compact and space saving design
Ceiling Ducted OAPU with highest external static pressure to cater for higher filtration that improves indoor air quality
Applications
Office
School
Hotel & Resort
Factory
Healthcare Facility
Specifications
| MODEL | FXMQ335 DSPFEC |
FXMQ350 DSPFEC |
FXMQ400 DSPFEC |
FXMQ500 DSPFEC |
||
|
Power supply |
3 phase, 50Hz, 380 – 415V | |||||
|
Cooling capacity(1), (5) |
KW | 34.9 | 40.0 | 45.0 |
56.0 |
|
| Btu/h | 119,114 | 136,520 | 153,585 | 191,128 | ||
| kcal/h | 30,008 | 34,394 | 38,693 | 48,151 | ||
| Coil |
Type | Aluminium fins and Copper tubes | ||||
| Rows x Fins Per Inch | 3 x 12 | |||||
| Face area | m2 | 0.83 | ||||
| EC Fan | Type | EC centrifugal module – RadiCal® | ||||
| Drive | Direct drive | |||||
| Power Input | kW | 0.306 / 0.525 / 0.673(3) | 0.344 / 0.576 / 0.745(3) | 0.387 / 0.632 / 0.811(3) | 0.498 / 0.525 / 0.673(3) | |
| Rated Air flow rate | cmh | 2,600 | 3,000 | 3,400 | 4,280 | |
| cfm | 1,530 | 1,766 | 2,001 | 2,519 | ||
| External static pressure | Pascal | 170 / 320 / 420 (3) | ||||
| Dimension (H x W x D) | mm | 720 x 1,645 x 850 | ||||
| Casing / Colour | Galvanized Steel | |||||
| Weight | kg | 148 | ||||
| Sound Level (2) | dB (A) | 44 / 46 / 48 (3) | 44 / 46 / 48 (3) | 45 / 46 / 48 (3) | 46 / 47 / 48 (3) | |
| Air Filter | Nil | |||||
| Piping Connections | Liquid | mm | ø 12.7 | ø 12.7 | ø 12.7 | ø 15.9 |
| Gas | mm | ø 28.6 | ø 28.6 | ø 28.6 | ø 28.6 | |
| Drain (4) | mm | PS 1B Internal Thread | ||||
| Remote Controller (option) | Wired | BRC1E63 | ||||
| Temperature Control | Microprocessor thermostat for cooling | |||||
Notes:
- Indoor temp.:33ºCDB,28ºCWB / Outdoor temp.:35ºCDB / Equivalent piping length: 7.5m, level difference: 0m. Leaving OAPU supply air temperature varies. Rated leaving evaporator air at around 18.0°CDB and below.
- Anechoic chamber conversion value, measured at a point downward from the unit centre, FCU with 2-meter supply duct and 1-meter return duct. These values may vary according to ambient conditions.
- External static pressure (ESP) is changeable at the electrical box by Daikin Service Team. This pressure means “High static” operating ESP @420Pascal at rated air flow rate. The External static pressure shown is the rated value at factory setting excluding filter static loss.
- Field supply insulated condensate drainage outlet pipe with proper U-trap installation is required. Fan coil unit drainage is without drain pump system design.
- Capacity index of FXMQ335, 350, 400 & 500 DSPFEC are 335, 350,400 & 500. Total connected indoor unit’s capacity index must be within 50-100% of the outdoor unit’s capacity index.
